Are you interested in electronics? But of course, the theory is boring. So let’s start with a simple electronic circuit for beginners or who want a circuit that can be made quickly and cheaply.
First of all, we should know all the basics before getting on with the real circuits.
What is a simple electronic circuit?
My daughter has asked me: “What is an electronic circuit?” It is a combination of electronic components in a specific way. Whereby we connect it with the conductor wires for the electrical current to flow through.
What is a SIMPLE electronic circuit? It is a small circuit, uses a few components, and the working process is easy to understand. In my opinion, to keep it simple, it is the circuit that combines components under 25 pcs.
Why do we learn about the simple electronic circuit?
- Sometimes our work is required small circuits, so there is no point in using a larger circuit. Also, the smaller the cheaper. Comparable to “Do not use a sledgehammer to crack a nut”.
- The understanding of a Simple electronic circuit will help us learn about larger projects better. Because a large project is a lot of small electronic circuits together.
If you want to learn more about electronic circuits in depth or technically. I recommend reading more on Wikipedia.
However, you are only an electronic hobbyist like me. Let’s see the circuit for beginners below.
Recommended Simple Circuits
Below are the electronic circuits we have picked for you.
Two LED flasher circuits
It is the simplest LED blinking circuit using transistor.
LM386 Audio Amplifier Circuit
This was my first ever amplifier circuit. Which can be powered with a 9V or 3.7V Li-ion battery with as little current. With an amplification gain of up to 0.5W.
Simple Condenser Mic Preamplifier Circuit
This small circuit can change sounds into audio signals using a 9V battery.
LED Chaser circuits using 4017 + 555
They use CD4017 to drive LEDs and IC-555 as an oscillator. It is for a beginner to learn a digital.
5-20 Minutes Timer using 555 timer
This small and portable timer circuit uses a 555 timer with a buzzer alarm sound. It has 5, 10, 15, and 20-minute presets chosen by switches.
Simple AC inverter circuit
This simple inverter circuit converts 12VDC to 220VAC using only 2 transistors, 2 resistors, and a transformer.
LM317 Power supply
Sometimes you might want a 1.5V power source that is not a battery, or maybe 13V, 4.5V, 7.5V, etc; build this variable-regulated regulator.
9V Regulator circuit using 7809
Let’s create this circuit to replace a 9V battery. It can deliver 10 times more current than the battery and save time and money to replace it.
12V Power Supply
It can supply all circuits that require a 12V DC source under 2A, or more with minor modifications. Read how to do: 12V Power Supply Circuit
6V, 12V, 24V Lead Acid Battery Charger
This shows many different lead-acid battery chargers for 6V, 12V, and 24V batteries using LM317 as the main component.
Other Simple Electronic Circuits For Beginners
Here is a list of basic electronic circuits, which you can look at below.
Sound Generator and Oscillator Circuits
Toy Organ circuit using transistors
Let’s play with a simple toy organ circuit. A daughter of mine is interested in piano. But at the moment we are not ready to study it. Believe it or not, we can create a simple piano circuit by ourselves.
Making Simple Buzzer circuit
Let’s make the electronic buzzer circuit in simple ways. But useful and well worth it and the price is lower than 1$. By using just a 9-volt battery only.
Police siren circuits
It is easy to do that. They have 3 circuit ideas for you.
Simple Bird Sound Generator Circuit
This Simple Bird Sound Generator Circuit was one of the first circuits I built as a child. It’s made up of only a transistor and a few others.
Simple Motion Sensor Alarm
If you have your own private space and do not want someone to intrude, this motion detector alarm circuit will definitely reduce your worries.
Signal injector circuits
This simple circuit can be used to repair televisions, radio receivers, amplifiers, etc. It produces a small frequency signal using a 1.5V battery as a power supply.
Triangle wave generator circuit using Schmitt-Trigger
It can create a Square or Triangle wave at the output with just a small number of electronic components. I made this a while back to learn about CMOS Gates and an Astable Multivibrator.
60 Hz Clock Generator Circuit using MM5369
It uses MM5369 and crystal as the main components. So, they can be used as a calibrator for standard frequency. They also give 1HZ, 1/60Hz, and 3.579MHz at TP.
ICL8038 Function Generator Circuits
If we need a function generator circuit. We have many ways to do it. Using the ICL8038 waveform generator is a great option. It is easy to use and inexpensive.
FM wireless microphone circuit diagram
AM radio receiver circuit diagram
Audio Amplifiers
TDA2822 stereo amplifier circuit
This is a small stereo power amplifier. People like it, me too. Why? Read more: TDA2822 amplifier circuit
- 4 transistor audio amplifier
- 3 transistors Audio Amplifier
- Simple transistor intercom
- Simple speaker delay
Simple Lighting and LED Circuits
1.5V LED flasher circuits
It’s efficient enough to last for 1 year. These circuits only use a few components consisting of two to three transistors, four resistors, and three capacitors.
Flashing Bicycle LED Taillight Circuit
Using transistors instead of ICs because they are simple and economical. It is quite simple because there are few components. But learning its working principles is very interesting.
Read more: DIY bike light
Simple Automatic Motion Sensor Light Circuit
Is there a way we could save as much electricity as possible?
LED chaser circuit using transistors
Since my daughter has tried making the LED chaser using ICs (CD4017 and NE555), it has worked well. But recently, she has been learning how to use transistors.
Simple Coin Toss Game circuits diagram
It is a type of simple electronic game that simulates a real coin toss with LEDs. You could build it in your free time to play and enjoy with others.
Solar Cell
Automatic Solar Light circuit
Let’s create a simple automatic solar light circuit or a Solar Night Light Circuit. My kids made it for daily use and to learn electronic circuits. They worked well, so we are happy.
Solar-powered Plant watering alarm circuit
It will sound an alarm whenever the soil is dry. So, we can water the plant to prevent it from dying. The solar cell works like a 6V DC power supply to save us money by not requiring batteries. It can be built easily with a few parts (without IC).
3 Automatic 12V Solar Light Circuits
If we need lighting around our home at night. But those areas are without an AC line because it is hard to do the wiring there. And we also want to save on electricity costs.
Agricultural Circuit
Automatic Plant Watering with a Solar Cell
Using a solar cell, a DC pump, a 555 timer, and an LM311 comparator. It worked well and was also very efficient, requiring only power from the solar cell rather than a battery.
Motor Controller and Timer Circuits
OFF Delay timer circuit
The easiest way is to turn on the light only when needed and turn it off when not. But in practice, we often forget to turn off the lights even when they are not needed.
30 min Transistor Timer Circuit
We can use this simple electronic circuit. To learn the basic timer circuit. The working of the circuit is based on learning the charge and discharge of the capacitor. And we can apply it to turn on-off electrical appliances. In the application, just put a relay instead of an LED.
Simple Speaker Turn-on Delay Circuit
Every time you turn the OCL power amplifier on, within the first 3 S, you hear a loud “tlub” sound. It is annoying. Also, caused by a voltage spike that can damage the speaker. But this circuit can help
Automatic LED Night Light circuits
Try making a simple automatic LED flashlight circuit with only 5 basic components. And, we would have learned about the transistor, LDR, LED, and more that work together as a voltage divider.
10 Key Code Lock Switch Circuit
We do not need to carry a load key and do not worry about your keys being lost. We just must remember to commit to code only.
Digital Electronics Projects using Flip Flops
I am going to show you these Flip-Flop Switch Circuits. Imagine you can use your life is better with your own electronic project.
Meter, Tester, Detector
Battery Voltage Monitor circuit
When the voltage level is lower below 12.4V. To extend the lifespan of the battery, we should always bring it to be fully charged. The circuit will alert us.
Non-Contact Voltage Tester circuit
Do you want a tool to check the AC main without touching it? This simple electronic circuit can do it and uses transistors without IC. Read more: Non-Contact AC Voltage Detector Circuit
Simple Water Level Alarm Circuit using a Transistor
It worked by sounding an alarm when the water level rose to the set level. So we can close the water valve in time and prevent an overflow with only basic electronic components.
Battery Voltage Monitor circuits
When the voltage level is lower below 12.4V. To extend the lifespan of the battery, we should always bring it to be fully charged. The circuit will alert us.
Continuity Tester Circuit with Buzzer and LED
This is a continuity tester circuit with a buzzer and LED. Also, I like this circuit. Because unnecessary to take my eyes off the tested circuit. We will hear the buzzer and see the LED glow.
You can use them to fast-check the many op-amps IC good with blinking LED circuits. It has a few parts so cheap and easy to build.
Battery Charger Circuits, Linear Power Supplies
7805 Constant Current Battery Charger circuit
7805 has many helpful. One thing is we can use them as constant current regulation. It is so easy and more convenient than using transistor circuits.
3.7V Li-ion Battery Charger Circuit
We made the circuit with commonly used components such as the NE555 timer and TL431 shunt regulator. It uses the principle of charging the battery with a low-current pulse signal. Making it a safe and impressionable performance charger.
Here is a constant current and voltage AA Ni-MH battery charger circuit.
Simple 1.2V AA Ni-MH Battery Solar Charger circuits
Create it with common parts for charging 1.2V AA, So easy and cheaper.
Constant current circuit using transistors
Learning experiments with a simple constant current circuits using transistors, and a few plain parts, was so helpful, especially the Ni-HM battery charger.
Gel cell battery charger circuit
It can charge any size of the Gel cell battery and extend the life of the Gel Cell battery. While the circuit is running, the LED indicates charging
DC Converter and Switching Mode Regulator Circuits
5V Low Dropout Regulator Circuit using transistor
The 6V input voltage can make the output regulator 5V 0.5A. So, the voltage across it is 1V only.
Read more: 5V transistor Low Dropout Regulator Circuit
3.7V to 5V Boost DC converter
Here is a 3.7V to 5V boost converter or step-up switching circuit using MC34063 and a few parts,1N5819,100uH. For 200mA-300mA of load current.
USB 5V to 12V DC-DC Step-Up Converter circuit
This circuit will increase the voltage from 5V to 12V load without IC. It is good to learn a switching mode regulated power supply in low power output.
1.5V or 3V Step-up Switching regulator circuit
5V 0.5A Simple Switching Regulator circuit
- 1.5V or 3V Step-up Switching regulator circuit
- 5V 2A Buck converter circuit using KA34063
- USB 5V to 1.5V/ 3V Step Down Converter
- 1.5V to 5V boost converter circuit
Conclusion
You will see that these circuits are simple, or in some cases, basic circuits, which can help solve our problems. We hope you get the most out of it and are able to improve it over time.
