A smoke detector is part of a sophisticated alarm system. Which within the system is a professional, most will include Section detector gas, room filling ions. Or sensitive to radio signals. However, this circuit does not have to be so complicated. Just another 2 LDRs and LED detection. Only the number of IC LM1801, the circuit helps the device is much less. Designed for this purpose. It consists, in Section controlled by the Zener voltage. Second output reference voltage output, the compare unit. And Transistor output resistance current 500 mA with diode clamp. This circuit does not require a transformer. Can be connected directly to the home. So there are diode – D1 rectifier as ACV, R2 serves to reduce the voltage at IC1 properly. Capacitor C2 filters the power was smooth. By a Zener diode in the circuit to control the voltage constant. The principle of this circuit Is [...]
We like to collecting the electronic circuits, to the idea of building electronic projects. Under different scenarios.
The some circuit is not obsolete. For example, I wanted to create a simple flashing light circuit for my son. We are available multiple circuits, From a simple two transistor circuit which can be carved from Old PCB,In storage rooms.
Or electronics stores to buy are very cheap. Or, we use the number of IC NE555 is a very popular one.
This circuit is a Fuse status indicators for power supply 12V. If a fuse is normally, the LED is going to lights all the time. But when it lacks, the LED will be blinking. The value of this equipment in the circuit is suitable for a 12 volt power supply. However able to change the power supply 6 volt or 24 volt, By reducing the value of the resistor to half or increasing. The display section consists of a stable multivibrators (Q1-BC547, Q2-BC547). And the driver LED section (Q3), All circuits except for the R5 connect before the fuse. The output of the multivibrators is going to work all times there are power supply, by passed through the diode D2 to the input of the driver LED section (Q3‘s PinB) If the fuse is intact , the base current of Q3 has still always, by passed through R5 and D1,the [...]
They are digital logic probe circuits that you make easliy. Most digital circuits that used CMOS ICs. because I like using CMOS ICs. Because it needs a voltage of approximately 3V to 12V and the power consumption is low. If we use the battery power for longer than IC-TTL. But when problems need to Logic. We use a CMOS IC is suitable or more efficient. And in the third circuits. We use the display with sound. Is so easy to use.There are 3 circuits, as follows. (see below!) 1.Three state logic tester probe using IC-CD4001 The work of the Temple three state logic IC-CD4001 circuit be the circuit will use not gate IC in show supervision. In case of still have no input signal come in be liberate input pin of IC1/1 float keep. Which make have impedance very many, which have no LED anything shine come out. In first [...]
This be Random Number Generator Circuit there is the character is 10 LED Flasher by use IC 4017 and IC 4011 integrated circuit. For the 4017 IC is a 16-pin CMOS decade counter. It takes clock pulses from the clock input, and makes one of the ten outputs come on in sequence each time a clock pulse arrives. Usability press S1 forLED Flasherrespectively. By pressure (Close) S1 make LED all stick dim (Dimly). When liberate (open) S1 make LED stick bright at LED any one to one’s fate. Besides value expansion C1 be 4.7uF make LED flasher slow down. The detail is other invite friends see in the circuit leisurely.
I believes in that extremely amateur electronics many you, may ever build the LED flasher or light blinks or the LED Chaser prevent come to already. Today I begs for to advise the circuit LED Chaser, by have LED show 10 amounts together. blink stick bright chase go to continually. By have IC CD4017 circuits precede at drive a tube LED all. Which its work be Counter circuit good just this besides. Still have IC 555 wait for feed Clock with then can fine the speed of the winking with VR1 good easy. The detail is other see in circuit picture better. Circuit LED Chaser by IC 4017 + IC 555
