Previously, we had built the Automatic Solar Light circuit and had been using it for many months. It has fair efficiency for everyday lighting. But this circuit has two problems: a dim light level and batteries that are hard to find and quite expensive.
But now my daughter has built this Simple solar light circuit version II. It has a better performance than the first one.
- It got far brighter because she used two white SMD LEDs.
- Use a 3.7V Li-ion battery instead, which is widely used. Making it easier to find than the 1.2V Ni-MH battery.
- And the circuit is also simpler.
And of course, we also use recycled components. Thus saving us money and helping us learn more about using them.
How it works
Now let’s look at the block diagram of this circuit. It will help us visualize the circuit we would need.
First, let’s say it’s daytime.
An electrical current from the solar cell charges the battery, and some current also goes to the control, turning the LEDs off.
Simple Solar Li-ion battery charger circuit
This is the simplest Solar Li-ion battery circuit, consisting of only three components:
- Free 3.7V Li-ion Battery
Nowadays, we prefer to use Li-ion batteries over other types of batteries because they have higher efficiency. It supplies a voltage of around 3.7V (up to 4.2V). Similar to a lead-acid battery, it doesn’t need to run out of power before recharging; it also maintains power for a long time, among other advantages. Which we will learn about more later.
This type of battery can usually be found in old mobile phones and other similar devices. They come in 3.7V 800mAh to 1000mAh. Alternatively, you can get a BL-5C for about $1, which is cheaper than a 1.2V 950mA Ni-MH battery.
It has similar properties to lead-acid batteries in that when the power is full, there will be a voltage of about 4V. While charging, be careful not to let the voltage exceed 4.2V and should charge with a low current.
Recommended: Recycle Free Li-ion battery from E-waste
6V 1W Solar cell
Another important component of this circuit is the solar cell panel, which should be capable of supplying a voltage of about 5V to 6V with a size of 1W to 2W. It will supply a current of about 100mA.
When exposed to sunlight for about 5 to 7 hours, it should have charged the battery to 80% or more. It would not exceed the voltage rating of the 4.2V battery, complying with battery specifications.
This low current does not make the battery heat up at all. We have tried this method many times and in many circuits. It has worked well and is suitable for small and economical circuits.
Assume we use an LED (load) that consumes about 60mA of current, but the battery has about 600mA of current; it can provide light for about 10 hours, almost the entire night.
Read Also: Simple Li-ion Battery circuit with automatic cut-off
- 1N5819 Diode
We only use a single diode to prevent reverse current from flowing from the battery to the solar cell.
In the circuit above, the current from the solar cell flows through D1 to charge the Li-ion battery. When there is less sunlight, the higher voltage from the battery cannot flow back to the solar cell.
Because there is a D1 blocking it, the current can flow only one way. The energy in the battery is stored and gradually increases until it is full.
In contrast, at night or without sunlight, there is no power from the solar cell, as shown in the block diagram below.
So, there is no power from the charger as well. The control detects this state. It then switches to driving the power from the battery to light up the LED instead.
Free Super bright LED
We are going to use this super bright LED we got from recycling a white SMD LED from the broken T8 tube. It is very bright; for two LEDs, it uses only 60mA of current. We connected them together in parallel and connected the current limiter resistor for each LED.
When used with the 800mAh Li-ion battery, it can remain on for more than 10 hours, or almost the entire night.
Turning it into circuit diagram
Next, we have to come up with the circuit according to the block diagram above.
During the day
(1) The solar cell receives sunlight, generating electricity to charge the battery through D1.
(2) At the same time, some current will flow through R1 as a biased current to the base of Q1. It causes Q1 to conduct current or turn on.
(3) The main current flows through D1, R2, and the collector-emitter of Q1 to the negative. Thus, there is no biased current to the base of Q2, turning off Q2 and the LEDs as well.
Read also: Small Automatic Plant Watering with a Solar Cell Power System
During the Night
Now there is no power from the solar cell at all. So, there is no current flowing through R1, and Q1 also turns off.
(1) The battery is fully charged, so the current flows back out. But it cannot flow through R1 because it is blocked by D1, which is in a reversed bias state.
Forcing the current to flow through R2 instead, as a biased current to the base of Q2.
(2) and (3) are in play after the Q2 is turned on and drives a main current through both LEDs. So, LED1 and LED2 light up.
Next, we take each part and assemble them together into a complete circuit.
Read more: Simple Circuits
How to build
My daughter built this project on a solderable breadboard PCB and a wooden board because it’s simple and economical.
Conclusion
After we have created this second version of the Simple Solar light circuit, we know that it is more efficient and easy to build than the previous one. Because the SMD LED is very bright and the 3.7V Li-ion battery provides higher power with a smaller size.
In the future, we will try to build a larger circuit, and we hope it will have more use for you.
GET UPDATE VIA EMAIL
I always try to make Electronics Learning Easy.
Related Posts
I love electronics. I have been learning about them through creating simple electronic circuits or small projects. And now I am also having my children do the same. Nevertheless, I hope you found the experiences we shared on this site useful and fulfilling.
Very good circuit!
Thanks for seeing that this circuit is good. I intend to do it a lot. 🙂
Goodday,
The circuit look solid.
But I don’t see under- and overcharging protection for the battery.
Maybe you could add a DW01-P and a FS8205A to protect an 18650 lithium battery.
These days are cloudy and the battery may not be fully charged.
Wessiez
Good day!
Thanks for your feedback!
That’s right, I haven’t installed any protection circuits yet. Because I just started learning it. You are so cute. Your comments are great. I will study the DW01-P and FS8205A and use them in our next circuit. If you have free time, Please advise me again. May you have lots of happiness, God bless you 🙂
I want to charge a 12v battery with maybe 2000mAh but you’re ratings is for 6v 1watt solar and 3.7v battery
So can I double the components values so it fits the 18v 3watt or more for my project!?
Like ai just need to charge a battery 12volts and need a similar circuit am trying to use this circuit and edit it but values doesn’t suit my project
Which is temperature controlled DC fan, powered by rechargeable battery done by a solar so that’s what am trying to build the recharging part. The fun circuit is complete
Hello,
I would like to express my opinion. As I understand. Because my English is not very good.
You use a 12V 2000mAh battery. It can be charged with an 18V 3W solar cell.
Is your load a 12V Lamp? How many watts is it?
I don’t quite understand. your details But your question is interesting. Next time I will try these circuits.
Ok my question is.
What type of resistors and solar panel ratings can I use in similar project to recharge a 12volts 2Ah Li-ion battery.
Coz the values here in this project are small coz the solar is rated 6v 1watt which can’t charge a 12v 2Ah Li-ion battery and be able to power a 12volts DC fan at the moment
Thank you for your additional message.
Unfortunately, I have limited time at the moment. I would also like to draw a picture of the instructions for you. Because I explain quite slowly. Maybe I don’t quite understand.
The system in this article is the simplest and most economical. But it cannot control the charging current. It is very important that your battery has a BMS, which is usually found in 12v Li-ion batteries. It will protect against overcharging (4.3V) and undervoltage (2.5V).
The next step is to choose a solar cell. It should have a size of 18V/10W. It will release a charging current of approximately 0.4A to 0.5A. If you charge it during the daytime, it will have full power in about 5 hours.
The important thing is, what is the current rating of your load?
Let me give an example: if you use a 12V/3W LED, it will use a current of about 0.25A (3W/12V), or you can use the LED for 8 hours (2A/0.25A).
But if it’s a 12V motor, I’m not sure. How much current does it need? It is important to Selecting a transistor, such as a TIP41 transistor, can use a maximum current of 2A continuously. Then gradually find the value of other devices. You can try changing.
Thanks,
I was looking into my project and your answers are exactly what I was looking for. Thanks 🙏
You are welcome. I hope you done on your project. If I have free time we will also try it.
