Voice Bandwidth Filter
This circuit passes frequencies in the 300Hz – 3.1kHz range, as present in human speech. The circuit consists of cascaded high-pass and low-pass filters, which together form a complete band-pass filter. One half of a TL072 dual op amp (IC1a) together with two capacitors and two resistors make up a second-order Sallen-Key high-pass filter. With the values shown, the cut-off frequency (3dB point) is around 300Hz. As the op amp is powered from a single supply rail, two 10kO resistors and a 10µF decoupling capacitor are used to bias the input (pin 5) to one-half supply rail voltage.
The output of IC1a is fed into the second half of the op amp (IC1b), also configured as a Sallen-Key filter. However, this time a low-pass function is performed, with a cut-off frequency of about 3.1kHz. The filter component values were chosen for Butterworth response characteristics, providing maximum pass-band flatness. Overall voltage gain in the pass-band is unity (0dB), with maximum input signal level before clipping being approximately 3.5V RMS. The 560O resistor at IC1b’s output provides short-circuit protection.
Author: M. Sharp – Copyright: Silicon Chip Electronics
Source: http://www.extremecircuits.net/
Related Links
Bandpass Filter
Low Pass Filter
High pass filter
Active bandpass filter
1KHz Bandpass Filter by IC LM324
Low Pass Active Filter by LM741
60Hz Notch Filter by LM741
Active high pass filter circuit using LM741
Categories: Oscillator generator, RF-Radio Frequency Tags: active bandpass filter, Bandpass Filter, high pass filter, Low Pass Filter
Subwoofer Filter low pass frequency by LF347
This be subwoofer filter low pass frequency circuit, for filter especial low frequency has passed by still the amplifier microphone. By this circuit uses op-amp IC number LF347 , perform the circuit filters low frequency change well, It make the sound that go out to have only low frequency ,about 100HZ not exceed. By have Switch choose frequency level that can want as well. This circuit should choose high-quality equipment, because decrease the noise. The detail is other , see in the circuit.
Related Links
More circuit about Low Pass Filter
More about subwoofer circuit
More circuit about bass amplifiers
Pre Tone Control Stereo (bass-mid range-treble) by IC NE5532
Bass Tone Control Preamplifier with Low Cut
Bass Boost section + Output Driver With IC
Categories: Audio diagram, Power Amplifier, Pre Amplifier Tags: Low Pass Filter, subwoofer circuit
Low pass filter circuit 10KHz using uA741
This be the circuit filters 10KHz low size frequencies s use IC op-amp the highly popular number uA741. By this circuit convenients for to apply to input and output of the circuit changes analog signal be digital or the circuit changes digital signal be digital. In sound system of digital for synthetic the voice or music give for make wave form output the smooth. And press the noise that happen at output. When small-sized signal was managed with decrypt linear the size is 8 bit. Read more
Related Links
Low Pass Filter
Low noise circuit
RF bandpass filter
Noise Filter
Low Pass Filter For FM 88-108 MHz
Subwoofer Filter low pass frequency by LF347
low pass filter subwoofer by TL072
Categories: Op-amp circuit, Oscillator generator Tags: Low noise circuit, Low Pass Filter, ua741
