How to use a phototransistor circuit | Light controller switch

I am going to show you how to use a phototransistor circuit is simple. To make it a light controller switch or relay with basic components like a transistor, IC, and more. Imagine when The Sunlight then the Relay Switch on to load as a fan runs. we are happy.

Then sundown. the relay switch turns off and no wind to us. Is it easy? It can also be used to detect a light beam, headlights, etc.

Light Actuated Relay Circuit using PhotoTransistor

See below it is the Light Actuated Relay Circuit for controlling Electrical appliances by the light. The prominent point of this circuit be meet the light has faster than using the LDR control circuit. When the light leaves work suddenly. When meet the light makes Photo Transistor work bias current change it has made the transistor works to cause Relay work with.

Light Actuated Relay Circuits by Photo Transistor

The VR1 perform fine decorate the rapidity of the circuit. This circuit is the circuit is simple. The equipment that use to replace such as Q1 = 2N2222 use other numbers can replace almost be finished request a kind NPN alike enough such as BC549 or BC337 or C1815 or C945 etc.

For oval should use 6V-9V sizes that are valuable the resistance within relay coil about 500ohm. Other detail has a little and build easily. What is more? learn the second circuit.

Read first for beginners: How do transistor circuits work

Simple phototransistor light controller circuit

This is Simple light controller circuit that is controlled light-activate. Which use the inverter gate IC-40106 as main components in compare and controlled switches, and common phototransistors as sensors

The Operation of switch has several forms. The most basic way is to press the switch directly. If modern must be controlling by Infrared light or remote control.

As well as uses radio frequency to control turn on / off switch. Even common light so can control turning on / off switch.

Light sensor controller using phototransistors

Mini switch controlled with light using CD40106

The working principle


The circuit in Figure 1 is the mini switch controlled with light which use phototransistor as a light receiver there are a schmitt trigger IC(CD40106) as drive an output current to load or the external circuit.

It can provide output current up to 25 milliamperes are circuit that use a few together components, Can be directly connected to small loads. or to drive the relay or an optocoupler type. to drive the load that use with AC volts or also DC high voltage.

The working of circuit when has light to the phototransistor-Q1 cause has current flow between collector-emitter junction, and has voltage drop across a potentiometer-VR1 as voltage “high” to trigger to a first schmitt trigger-IC1/6 until output is “low”. And have others five schmitt triggers that parallel into the inverter gate provide voltage output is “high”. The connecting in parallel to the maximum drive current or the about 25 mA.

The resistor-R1 and capacitor-C1 are connected into the RC networks to prevent noise, which may be inserted. If the problem of noise. may add capacitance-C1 little up. The potentiometer-VR1 to adjust a sensitivity in as switch of Q1. When has a lot light to it. The circuit can be used with the power supply up to 16 V

How to build

This project is not used a few components so can assemble on the universal PCB board as Figure 2.
In the assembly circuit,Starting equipment lowest first to Beautiful and easy to the assembly. Start from Diode and then resistors and sort of high continuously.

components-layout-of-mini-switch-controlled-with-light


the components layout of this projects

For the device has various polarity should be careful in the assembly circuit. Before placing these components will must set the polarity at PCB and the part match together because If you put backward, may cause equipment or circuit damage.

The components list
Resistors size ¼ W +5%
R1: 10M
VR1: 1M Potentiometer
Capacitors
C1, C2: 0.1uF 50V, Polyester capacitors
Semiconductor
Q1: SFH309-6 Photo transistors
IC1: CD40106__CMOS Hex Schmitt Triggers
Others
Universal PCB board
